$15,249 2 or 4 Passenger
~~~
$18,249 6 Passenger
Choose from 4 standard colors:
Burgundy
Black
Silver
White
2 or 4 Passenger Seating
Powerful AC 17.5hp Drive Motor
SEVCON 3" LCD Display Screen
On Board Delta-Q Charger
Automotive style Master ON/OFF Key
Street Use
Self Diagnostic On Screen Capability
2 Locking Glove Boxes
2 Cup Holders
Adjustable Side Mirrors - Left and Right
Center rear view mirror
R-Flex Plastic Body
Tubular Suspension
Independent Front Suspension
Hard Top (Extra)
Flip Back Rear Cargo Seat
3 Point Seat Belts certified to FMVSS #209
4 Wheel Brakes
Color Matched Roof (extra)
Headlights
Rear fender protectors
Bag-well liner or Bag holder
Dual Tail lights with LED Brake Lights
High mounted Third Brake light for Safety
Front and Rear Side Reflectors
Horn
Front and Rear Turn Signals
13 & 14 inch Wheels
Triple Leaf Springs
Chrome Lug Nuts
Two-tone Upholstery
Standard Options
13 & 14 Inch Wheels
Sony Xplod AM/FM CD Player with Speakers
Removable Dual Golf Bag Holder Attachment
Golf Ball Washer
Sand and Seed Dispenser
Beverage Cooler
Storage Basket
Car Cover, Tops, LSV Certificate
Some Options Available:
Overall Length
138 Inches
Overall Width
42 ½ Inches
Height to top of Windshield
71 Inches
Wheelbase
65 ½ Inches
Ground Clearance
5 Inches
Weight
(standard vehicle no batteries)
738 lb.
Weight
(Curb, with Batteries)
1,180 lb.
Weight
(GVWR)
2,000 lb.
Wheels
Front
13”x7”
Wheels
Rear
14”x7”
Tire Size
Front
215/ R13
Tire Size
Rear
215/ R14
Brakes
Front
Hydraulic Disk
Brakes
Rear
7” Mechanical Drum Type
Drive Motor
Direct Drive
48 Volts
3-phase Industion
17.5 hp peak
Transaxle
Double Reduction, high speed gears
Electrical System
48 volts DC
Batteries
Six (6) @ 8V each in series = 48V DC
Battery Charger
Delta-Q
Speed Controller
SEVCON Gen4 @ 450 Amp Continuous
Steering
Rack and Pinion
Chassis
Aluminum I-Beam
Body Finish
Automotive Paint
Interior Material
Marine-type Vinyl
Carpet
Marine-type Synthetic
Forward Speed
>20 MPH and <25 MPH
Braking Distance
(from 20 mph)
<20 feet
Standard Seating Capacity
4
SPECS
E-Wagon Golf Carts
Call or Text for a quote
Cool Custom Cars
